The PXC2190 PXI Express Embedded Controller is based on the 7th generation Intel® Core™ i7 processor, specifically designed for hybrid PXI Express-based test systems, providing maximum computational power for various test and measurement applications. The PXC2190 combines the 7th generation Intel® Core™ i7 processor with up to 32 GB of 2400 MHz DDR4 memory.

Request For Quote Or
Whatsapp Now

Description

Multiple independent tasks in a multitasking environment. The PXC2190 supports four-link x4 or dual-link x8 PXI Express link functionality, with a maximum system throughput of 16 GB/s over the PCI Express 3.0 bus.

The PXC2190 offers ample interface flexibility, including two DisplayPort connectors for connecting to two monitors, dual USB 3.0 connections for high-speed peripherals, dual Gigabit Ethernet ports (one for LAN connection and the other for controlling LXI instruments), four USB 2.0 ports for peripheral devices and USB instrument control, and a Micro-D GPIB connector for GPIB instrument connection, making it suitable for controlling hybrid PXI-based test systems.

Technical Parameters

Item

Data
Processor
Intel® Core™ i7-7820EQ 3.0GHz (Turbo 3.7GHz)
Bus Specifications
PCI Express 3.0 (compatible with 2.x and 1.x)
Hard-drive
240 GB (or higher) SSD / 500 GB (or higher) HDD
Front Panel Interfaces
Dual GbE, four USB 2.0, dual USB 3.0, GPIB (IEEE488) controller
Two DisplayPort connectors, one RS-232/422/485 D-SUB9 connector
Trigger I/O for advanced PXI triggering functions
Mechanical Characteristics
Compliant with PXI Express Hardware Specification Rev. 1.0, 3U, 3 Slot wide
Operating System
Windows 10 (64 bit)
Environmental Adaptability Requirements
Operating temperature: -0°C to +55°C
Storage temperature: -20°C to +70°C
Relative humidity: 5% to 95% (non-condensing)
